JS-K5-CNC
INTELLIGENCE WOORWORKING DRILLING AND MILLING PROCESSING CENTER
Min. Width of Plate : 50mm
Max. Thickness of Plate : 50mm
Motor Voltage : 380V/50Hz
Overall Dimensions : 2800*2190*1700mm
Working Distance of Y Axis : 1490mm
Max. Positioning Speed of A Axis : 35m/min
Main Spindle Mode : Slotting & Round Milling
Main Spindle Speed : 24000rpm
Max. Width of Plate : 900/1250mm
Height of Working Table : 950mm
Air Pressure : 0.6-0.8mpa
Working Distance of X Axis : 1250mm
Max. Positioning Speed of Y Axis : 80m/min
Working Distance of Z Axis : 50mm
Knife Handle Diameter : 1/2
Min. Length of Plate : 250mm
Total Power : 8.2kw
Net Weight : 2600kg
Max. Positioning Speed of X Axis : 90m/min
Working Distance of A Axis : 80mm
Max. Positioning Speed of Z Axis : 30m/min
Main Spindle Motor Power : 2.2kw
